Heavy Duty Rock Grapple for Skid Steers – 50–75 HP

Heavy-Duty Skid Steer Rock Grapple Attachment for Rock Removal, Land Clearing & Debris Handling

Move more rocks, clear debris faster, and tackle demanding jobs with the Heavy Duty Rock Grapple for Skid Steers. Engineered for 50–75 HP skid steer loaders and compact track loaders, this rugged hydraulic rock grapple combines heavy-duty steel construction, powerful dual hydraulic cylinders, and reinforced grapple tines to handle challenging rock removal and land clearing applications.

Available in63", 66", 72", 78", 81", and 84" widths, this skid steer rock grapple is designed to lift, grab, separate, and transport rocks, roots, brush, and construction debris while allowing loose dirt and smaller material to fall through the tines.

Featuring1/2-inch thick upper grapple tines, 3/8-inch thick lower tines, and 2-3/8-inch tine spacing, this heavy-duty rock grapple provides strength, durability, and efficient material separation.

Whether you're clearing rocky farmland, preparing construction sites, removing large stones, or cleaning up demolition debris, this hydraulic skid steer grapple helps reduce manual labor and increase jobsite productivity.

Heavy Duty Rock Grapple Features & Benefits

• Built for 50–75 HP Skid Steers: Designed for demanding rock handling, land clearing, and construction applications.

• Six Available Widths: Choose from 63", 66", 72", 78", 81", and 84" to match your machine and job requirements.

• 1/2" Heavy-Duty Upper Tines: Reinforced steel grapple tines provide strength for gripping rocks, roots, and irregular materials.

• 3/8" Lower Tines: Durable lower tines help separate rocks and debris from loose soil.

• 2-3/8" Tine Spacing: Allows dirt and smaller material to pass through while retaining larger rocks and debris.

• Dual 2" × 10" Hydraulic Cylinders: Deliver strong, consistent clamping force for secure material handling.

• 3/4" × 6" Cutting Edge: Heavy-duty cutting edge provides strength during digging, scraping, and material collection.

• Optional Weld-On Teeth: Available with a 1" × 8" cutting edge for more aggressive ground engagement.

• Optional Cylinder Rod Covers: Help protect exposed hydraulic cylinder rods from rocks, debris, and accidental impacts.

• Heavy-Duty Construction: Built to withstand demanding agricultural, landscaping, demolition, and construction environments.

Powerful Dual Hydraulic Grapples for Secure Rock Handling

The Heavy Duty Skid Steer Rock Grapple features two powerful2-inch bore × 10-inch stroke hydraulic cylinders designed to provide reliable gripping force when handling large rocks and irregular debris.

The hydraulic grapple arms secure material against the lower tines, helping operators lift, transport, and position heavy objects with greater control.

Unlike a standard skid steer bucket, a hydraulic rock grapple allows operators to clamp irregularly shaped materials that would otherwise be difficult to carry.

Benefits include:

• Improved control when handling large rocks and boulders

• Secure gripping of roots, brush, and construction debris

• Reduced material shifting during transport

• Faster loading and unloading

• Less manual handling and cleanup

• Increased productivity on demanding jobsites

For contractors and property owners working in rocky terrain, a heavy-duty hydraulic rock grapple can significantly improve material handling efficiency.

Reinforced Steel Tines Built for Tough Conditions

Rock handling requires an attachment capable of withstanding repeated contact with hard, abrasive materials.

This skid steer rock grapple features1/2-inch thick upper grapple tines and 3/8-inch thick lower tines, providing a durable structure for lifting, separating, and transporting rocks and debris.

The 2-3/8-inch tine spacing helps sift loose soil away from larger material, reducing unnecessary dirt collection.

This design makes the attachment especially effective for:

• Separating rocks from soil

• Removing surface stones from fields

• Collecting roots and brush

• Cleaning up construction debris

• Clearing rocky ground

• Handling mixed materials

The open-tine design also improves visibility of the material being collected compared with a solid-bottom bucket.

Heavy-Duty Cutting Edge with Optional Weld-On Teeth

The standard rock grapple features a3/4" × 6" cutting edge designed to provide durability during ground-level material collection.

For operators requiring more aggressive digging and ground engagement, an optional1" × 8" cutting edge with weld-on teeth is available.

The optional teeth help penetrate compacted material, loosen embedded rocks, and improve material collection in demanding conditions.

This makes the attachment versatile for rock removal, site preparation, and land clearing applications.

Optional Hydraulic Cylinder Rod Protection

Working with rocks, broken concrete, and demolition debris can expose hydraulic components to potential impact damage.

Optional cylinder rod covers are available to provide additional protection for the grapple's hydraulic cylinders.

These covers help shield exposed cylinder rods from debris and accidental contact, reducing the risk of damage during demanding applications.

Applications for Heavy Duty Skid Steer Rock Grapples

Rock Removal & Land Clearing

Grab, lift, and remove large rocks, roots, and other obstacles when clearing property or preparing land for development.

Agricultural Field Rock Picking

Remove surface stones and rocks from farmland while allowing loose soil to fall through the grapple tines.

Construction Site Preparation

Collect rocks, broken concrete, and jobsite debris before grading, excavation, or new construction.

Landscaping & Property Maintenance

Move landscape rocks, clear overgrown areas, and handle bulky debris without excessive manual labor.

Demolition & Debris Cleanup

Grip and transport broken concrete, masonry, and irregular construction materials during cleanup operations.

Forestry & Brush Removal

Collect roots, branches, brush, and other bulky vegetation during land management and property clearing projects.

Choosing the Right Skid Steer Rock Grapple Width

The Heavy Duty Rock Grapple is available in six widths to accommodate different machines and jobsite requirements.

63" & 66" Rock Grapples: Compact options for tighter working areas and properly matched 50–75 HP skid steers.

72" Rock Grapple: A versatile width for general rock removal, construction cleanup, and land clearing.

78" & 81" Rock Grapples: Wider options for increased material collection and coverage.

84" Rock Grapple: The widest model, designed for operators who need maximum coverage on large clearing and cleanup projects.

When selecting a rock grapple, consider your machine's horsepower, rated operating capacity, hydraulic system, attachment weight, and overall machine width.

Get More Done with a Heavy Duty Skid Steer Rock Grapple

Stop wasting time moving rocks, roots, and heavy debris with equipment that isn't designed for the job.

TheHeavy Duty Rock Grapple for Skid Steers delivers the strength, gripping power, and durability needed for demanding rock removal, land clearing, construction cleanup, and agricultural applications.

With reinforced steel tines, dual hydraulic cylinders, six available widths, and optional weld-on teeth, this attachment helps operators handle tough materials more efficiently.

Move more material. Reduce cleanup time. Get the job done faster.

Heavy Duty Skid Steer Rock Grapple Specifications

Additional Specifications – All Models

Specifications are based on the supplied product information. Verify attachment compatibility, hydraulic requirements, and machine operating capacity before ordering.

Frequently Asked Questions – Heavy Duty Skid Steer Rock Grapples

What is a skid steer rock grapple used for?

A skid steer rock grapple is a hydraulic attachment designed to grab, lift, separate, and transport rocks, roots, brush, concrete, and other bulky materials. Its open-tine design allows loose dirt to fall through while retaining larger debris.

What size skid steer is needed for this heavy-duty rock grapple?

This heavy-duty rock grapple is designed for skid steers with 50–75 horsepower. Operators should also verify hydraulic compatibility, machine lifting capacity, and attachment weight before use.

Can a rock grapple be used on a compact track loader?

Yes. A compatible compact track loader can operate a hydraulic rock grapple when the mounting system, hydraulic connections, and machine capacity meet the attachment requirements.

What is the difference between a rock grapple and a root grapple?

Both attachments use open tines and hydraulic grapple arms. Rock grapples are designed for handling and separating rocks and hard debris, while root grapples are commonly used for brush, roots, logs, and vegetation. Their applications often overlap.

Can a skid steer rock grapple separate rocks from dirt?

Yes. The 2-3/8-inch spacing between the lower tines allows loose dirt and smaller material to fall through while retaining larger rocks and debris.

What hydraulic cylinders are used on this rock grapple?

The attachment features dual 2" × 10" hydraulic cylinders designed to provide consistent clamping force for gripping rocks and other materials.

Are weld-on teeth available?

Yes. Optional weld-on teeth are available with a 1" × 8" cutting edge for more aggressive material collection and ground engagement.

Are hydraulic cylinder rod covers available?

Yes. Optional cylinder rod covers help protect exposed hydraulic components from rocks, debris, and impact damage.

What widths are available?

The Heavy Duty Rock Grapple is available in 63", 66", 72", 78", 81", and 84" widths.
