CFX450DB48
WAIN ROY ditching & grading buckets for excavators 95,000-110,000 lbs.
$10,519.00 - $17,258.00
4/24
CFX450DB / CFX455DB
STANDARD/HIGH CAPACITY DITCH CLEANING PIN-ON EXCAVATOR BUCKET
Ditching & Grading Buckets are used for ditch cleaning, grading, backfilling and loose material loading applications. They feature a wide and shallow tub design that offers a shorter tip radius allowing for the increased width without losing material penetration. Ditching & Grading buckets are ideal for use in sand, topsoil, and other loose or soft materials.
| AVAILABLE MOUNTS | DESCRIPTION | |
| OEM PIN ON | TWO HORIZONTAL PINS |  |
| DITCH CLEANING STD. CAPACITY |
CFX450DB |
|
| OEM PIN ON | CAPACITY (CU. YARD) | LBS |
| 48" | 1.28 |
1846 |
| 54" | 1.47 |
1996 |
| 60" | 1.65 |
2145 |
| 66" | 1.84 |
2296 |
| 72" | 2.02 |
2445 |
| 78" | 2.21 |
2595 |
| 84" | 2.39 |
2862 |
| 96" | 2.57 | 3171 |
| DITCH CLEANING HIGH CAPACITY |
CFX455DB |
|
| OEM PIN ON |
CAPACITY |
LBS |
| 48" | 1.44 |
2104 |
| 54" | 1.64 |
2265 |
| 60" | 1.85 |
2423 |
| 66" | 2.06 |
2584 |
| 72" | 2.27 |
2742 |
| 78" | 2.47 |
2902 |
| 84" | 2.68 |
3193 |
| 96" | 2.79 |
3513 |
| MAKE | MODELS: 45 MT 95,000 - 110,000 LBS |
| CASE |
|
| CAT |
|
| DOOSAN |
|
| HITACHI |
|
| HYUNDIA |
|
| JCB |
|
| JOHN DEERE |
|
| KOBELCO |
|
| KOMATSU |
|
| LIEBHERR |
|
| LINK-BELT |
|
| LIUGONG |
|
| TEREX |
|
| VOLVO |
|
