TLT3PO-60

WAIN ROY Tilt Bucket for 15MT Excavators 30,000 - 41,000 lbs.

MOUNTING
SIZE

WAIN ROY TILT BUCKETS

Tilt Buckets rotate up to a total of 90 degrees, 45 degrees each side of center, for greater control and flexibility during ditch cleaning, grading, backfilling and loose material loading and unloading applications. The tilting mechanism allows the bucket to rotate at various angles in order to form the surface to the desired shape without repositioning the machine. This is especially beneficial when working along roadways or in tight operating conditions.

45° rotation. Bolt‑on edge standard. Machine must be equipped with valve and lines down to end of dipperstick. Valve must have port reliefs. For Hydraulic Kit availability & pricing, contact Dealer Services.

TILT BUCKET

OEM PIN ON

WIDTH
CAPACITY (CU. YD.)
LBS
TLT3PO-60 60" 1.00 1875
TLT3PO-72 72" 1.13
2400

TILT BUCKET

WAIN ROY XLS / ORIGINAL

GANNON / CP / TAG

WIDTH CAPACITY (CU. YD.) LBS

TLT3QC-60

60" 0.90
1322
TLT2QC-72 72" 1.10 1468
MAKE MODELS: 15 TON 30,000 - 41,000 LBS
CASE
  • 9020B, CX160, CX160B, CX160D
CAT
  • 315C L, 315D L, 316F L (2017), 318F, DX160, M315C, M316C, M318C
DOOSAN
  • DX180LC-5, DX18LC, DX190-W, S175LCV
HITACHI
  • EX150, ZX160LC, ZX160LC-3, ZX160LC-6, ZX180
HYUNDIA
  • HX160L, HX180, R160LC-9, R160LC-9A, R170W, R180LC-9
JCB
  • JS160, JS160LC, JS180, JS190
JOHN DEERE
  • 160C LC, 160D LC, 160G-LC, 180G-LC, 590D, 595D
KOBELCO
  • ED150BR, ED160-3 BLADE RUNNER, ED160-5 BLADE RUNNER, ED190BR, SK140SRLC-5, SK160LC, SK170LC, SK170LC-10
KOMATSU
  • PC138USLC-11, PC138USLC-8, PC160LC-7, PC160LC-8
LIEBHERR
  • A314, A316, A914 Litronic, R313, R317, R914 Compact Litronic
LINK BELT
  • 160 X2, 160 X3, 160 X4, 160X
LIUGONG
  • CLG915D, CLG915E
MECALAC
  • 15MC, 15MWR
NEW HOLLAND
  • E175B, EH160LC
TEREX
  • TS180SR, TW150, TW160, TW160SR, TW170, TW190, TW220, TXC140LC-2, TXC180LC-2
VERMEER
  • CX254
VOLVO
  • EC160B, EC160C, EC160C-LC, EC160E, EW160C, EW160E, EW180C, EWR150E, EWR170E
WACKER NEUSON
  • GE1202, ME12002
