1DSS-3-ML

DIGGA DSS Heavy Duty Auger Drives for Mini Loaders

Size
Mounting
Options

5/24

AUGERS FOR MINI LOADERS

Digga's drilling augers for skid steer loaders are the ultimate in performance, quality and cost effectiveness. Over 30 years of design and development has produced the highest quality range of auger drives on the market today. Completely manufactured and assembled by Digga, using only the highest grade materials and strictest quality control.

Fitted with Digga / Eaton bell motors and input housing, the innovative design allows the gearbox to go down the hole to maximize drilling depth without extensions, eliminating downtime and minimizes maintenance, optimizing your returns.

Digga's new Halo Alignment System is the future of drilling. Located on the hood of the ring on the Drilling Drive, the Halo Alignment system eliminates the need for any spotter & ensures all holes drilled are plumb.

Digga drilling augers are backed by industry leading warranty and local factory support.

FEATURES

  • Compact Digga manufactured gearbox
  • Digga designed Eaton motor with optional intergrated pressure relief valve to eliminate the need for bulky valve blocks and reduce many potential leak points
  • 2 Piece shaft design ensures maximum side load ratings without increasing load on bearings
  • Lifetime shaft pull out warranty
  • Halo Alignment System available
  • 5 year gearbox and 3 year motor warranty
  • Over 30 years design and manufacturing experience
  • Easily converted to a screw anchor drive with the addition of our patented 'anti kickback valve'

AUGERS FOR SKID STEER LOADERS 2.5-3.8T

Digga's drilling augers for skid steer loaders are the ultimate in performance, quality and cost effectiveness. Over 30 years of design and development has produced the highest quality range of auger drives on the market today. Completely manufactured and assembled by Digga, using only the highest grade materials and strictest quality control.

Fitted with Digga / Eaton bell motors and input housing, he innovative design allows the gearbox to go down the hole to maximize drilling depth without extensions, eliminating downtime and minimizes maintenance, optimizing your returns.

Digga's new Halo Alignment System is the future of drilling. Located on the hood of the ring on the Drilling Drive, the Halo Alignment system eliminates the need for any spotter & ensures all holes drilled are plumb.

Digga drilling augers are backed by industry leading warranty and local factory support.

FEATURES

  • Compact Digga manufactured gearbox
  • Digga designed Eaton motor
  • Halo Alignment System available
  • 2 Piece shaft design ensures maximum side load ratings without increasing load on bearings
  • Lifetime shaft pull out warranty
  • 5 year gearbox and 3 year motor warranty
  • Over 30 years design and manufacturing experience

Includes:

  • HOSES & FITTINGS (66" LONG)
  • 2" HEX SHAFT





SPECS 1DSS 2DSS
TORQUE (FT-LBS @ 3000 PSI 1,467 2,254
MAX TORQUE FT-LBS @ 3500 PSI 1,712 2,630
RECOMMENDED FLOW (GPM) 6-16 10-26
MOTOR TYPE EATON EATON
MAX PRESSURE - DO NOT EXCEED 3500 PSI @ 16 GPM
MAX FLOW - DO NOT EXCEED 30 GPM @ 1800 PSI
MAX HORSE POWER 33 33
PRESSURE RELIEF VALVE N/A N/A
STANDARD OUTPUT SHAFT 2" HEX 2" HEX
HALO OPTIONAL OPTIONAL

RECOMMENDED AUGER A4 / RC4 A4 / RC4
MAX DRILLING DIAMETER (CLAY / SHALE)* 12" 24"
MAX DRILLING DIAMETER EARTH* 24" 30"
WEIGHT (LBS) 101 123
OVERALL LENGTH (IN) 24.5" 25.9"
DIAMETER (IN) 7.4" 9.4"

(*) Max/min drilling diameter (DIA) dependent on ground conditions. Guide is a recommendation only.

SPECS 3DSS 4DSS 4DDS
TORQUE (FT-LBS
@ 3000 PSI
2,829 3,275 3,583
MAX TORQUE FT-LBS
@ 3500 PSI
3,300 3,821 4,180
RECOMMENDED FLOW (GPM) 10-30 10-30 10-36
MOTOR TYPE EATON EATON EATON
MAX PRESSURE -
DO NOT EXCEED
3500 PSI @ 16 GPM 3500 PSI
@ 27 GPM
MAX FLOW -
DO NOT EXCEED
30 GPM @ 1800 PSI 42 GPM
@ 3100 PSI
MAX HORSE POWER 34 34 55
PRESSURE RELIEF VALVE N/A N/A INCLUDED
STANDARD OUTPUT SHAFT 2" HEX 2" HEX 2" HEX
HALO OPTIONAL OPTIONAL OPTIONAL

RECOMMENDED AUGER A4 / RC4 A4 / RC4 A4 / RC4
MAX DRILLING DIAMETER
(CLAY / SHALE)*
24" 24" 24"
MAX DRILLING DIAMETER
(EARTH)*
30" 30" 40"
WEIGHT (LBS) 123 125 180
OVERALL LENGTH (IN) 25.9" 25.9" 29"
DIAMETER (IN) 9.4" 9.4" 9.4"
(*) Max/min drilling diameter (DIA) dependant on ground conditions. Guide is a recommendation only.
Inquire now for your nearest dealer or for product inquiries Digga North America - 3DSS Auger Drive Unit



The 1DDS, 2DDS, 3DDS and 4DDS are designed for heavy duty drilling. These augers can only handle 6 to 30 GPM flow depending on the model. These augers have a four way swing mounting (forward and back, side to side) that is extended. The extension allows you to use 4' bits on a mini loader auger drive. You can special order a Bobcat MT mounting but you will need to call me to make that happen. The package includes The hoses, fittings, drive and mountings so it is ready to go on the job site.
