MMH4
EZG mobile mud mixer
$4,995.00 - $9,395.00
Mobile Mixers
The Mobile Mud Hog® was built to allow easy pours in difficult terrain. Four different mobile models are available, ranging from our compact 4 cu. ft. unit to our largest 20 cu. ft. unit. With a range of capacities and options to choose from, you can easily find a model that meets your needs.
Our products are known across the industry as the leading equipment for quality, performance, and safety. Our Mud Hog Mixing Stations are the premier standard for grout, mortar and concrete workhorse mixers, delivery and support systems. Distributed internationally, EZG Mud Hog mixers are designed with a range of capabilities and options to make your job easier.|
|
MMH4 |
MMH9 |
MMH12 |
MMH20 |
|
Dimensions |
48" x 32" x 38" |
54" x 36" x 42" |
72" x 36" x 44" |
85" x 45" x 52" |
|
Capacity (cu. ft / 80 lbs. bags) |
4 cu. ft. (.11 m³)/3-4 bags |
9 cu. ft. (.25 m³)/ 8-9 bags |
12 cu. ft. (.34 m³)/11-12 bags |
20 cu. ft. (.57 m³)/19-20 bags |
|
Gross Weight |
950 lbs. (431 kg) | 1950 lbs. (885 kg) | 2880 lbs. (1306 kg) | 4400 lbs. (1996 kg) |
|
Empty Weight |
350 lbs. |
600 lbs. |
1000 lbs. |
1400 lbs. |
|
Drum Thickness |
3/16" |
¼" |
¼" |
3/8" drum end and 5/16" drum wrap thickness |
| Aggregate Size (in.) |
¾" (1.9 cm) |
¾" (1.9 cm) |
¾" (1.9 cm) |
¾" (1.9 cm) |
|
Power Supply |
Auxiliary hydraulics |
Auxiliary hydraulics |
Auxiliary hydraulics |
Auxiliary hydraulics |
|
Drive System |
Hydraulic |
Hydraulic |
Hydraulic |
Hydraulic |
|
Dump Action |
Manual gate |
Manual gate |
Hydraulic gate |
Hydraulic gate |
|
Min. Hydraulic Flow Rate |
4 gpm @ 2000 PSI |
4 gpm @ 2000 PSI |
10 gpm @ 2400 PSI |
10 gpm @ 2400 PSI |
|
Max. Hydraulic Flow Rate |
16 gpm @ 3000 PSI |
26 gpm @ 3000 PSI |
40 gpm @ 3000 PSI |
40 gpm @ 3000 PSI |
|
Material Discharge (yd.³/min.) |
½ |
½ |
½ |
½ |
