KATO 25V5 MINI EXCAVATOR

COMPACT POWER, PRECISION & RELIABILITY

The KATO 25V5 Mini Excavator delivers zero tail swing performance, enhanced digging force, and responsive hydraulics in a compact, stable design. With a 10% increase in digging power and a fast-acting 4-pump hydraulic system, the 25V5 is ideal for construction, landscaping, utilities, and confined job sites where precision and maneuverability are essential.

Designed for operator comfort and efficiency, the 25V5 features smooth hydraulic pilot controls, a fuel-efficient Kubota engine, and a spacious operating area. Safety is prioritized with an auto-parking brake and neutral engine-start system, reducing operational errors. Its compact footprint, strong breakout force, and versatile offset boom allow for efficient excavation, skimming, and loading in tight spaces.

KEY FEATURES & BENEFITS

• Operating weight: 5,919 lbs

• Bucket capacity: 2.8 ft³, width: 18"

• Bucket digging force: 4,721 lbs

• Swing speed: 9 RPM, travel speed (low/high): 1.5 / 2.7 mph

• Gradeability: 30°, ground pressure: 4.5 psi

• Offset boom with hydraulic cylinder, boom swing angle: 50° left / 80° right

• Total hydraulic system flow: 20 GPM, max auxiliary flow: 11 GPM

• Engine: Kubota D1305-E4B, 23.6 HP @ 2400 RPM, fuel tank: 11 gal

• Standard dozer blade: 5’1” x 1’3”, lift/drop: 1’2” / 1’5”

• Zero tail swing design for safe operation in tight areas

The KATO 25V5 Mini Excavator combines precision, power, and durability in a compact package—perfect for operators seeking reliable performance and efficiency in confined spaces.

Specifications

Engine

Boom Swing System

Hydraulic System

Dozer Blade
