SPIDER ATTACHMENTS

SPIDER industrial grapple for skid steers

Style
Size
EDGE

Industrial grapple buckets have a solid floor and two independent grapples. These grapples are typically used in demolition, scrap and recycling applications.

HEAVY DUTY GRAPPLE FEATURES

  • Independent grapple tines, for grappling uneven loads
  • Strong 2″ x 10″ cylinders with 9,500 lbs of grappling force
  • Comes equipped with Parker brand hoses, fittings, and couplers
  • Reinforced quick attach
  • Fully protected hoses
  • Covered hydraulic cylinders
  • Oversized, greaseable 114” pins
  • Reinforced steel bottom
  • Available with optional bolt-on reversible double edge
  • Treaded step
  • Reinforced back and bottom

EXTREME DUTY GRAPPLE FEATURES

  • 1″ thick independent grapple tines, for grappling uneven loads
  • Strong 2″ x 10″ cylinders with 9,500 lbs of grappling force
  • Comes equipped with Parker brand hoses, fittings, and couplers
  • Reinforced quick attach
  • Fully protected hoses
  • Covered hydraulic cylinders
  • Oversized, greaseable 114” pins
  • Reinforced steel bottom with 1″ thick sides
  • Available with optional bolt-on reversible double edge
  • We stock sizes: 72″, 78″, 84″, and custom sizes also available
  • Treaded step
 MODEL

HEAVY

DUTY

EXTREME

DUTY

BIG

MOUTH

SIZES 60",66",72",78",84" 72",78",84" 72",78",84",96"
CYLINDERS 2"X10" 2"X10"
GRAPPLE FORCE 9500 LBS 9500 LBS
OPENING 31 7/16" 31 7/16"
EDGE 3/4"X6" 1"X8"
BOTTOM 1/4" REINFORCED 1/4" REINFORCED
MACHINE RECOMENDATION UNDER 75 HP OVER 75 HP OVER 75 HP
