WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.
WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.
WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.
WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.
WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.
WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.
WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.
WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.

RB12PO-18

WAIN ROY Ripper Buckets for 12MT Excavators 20,000 - 30,000 lbs.

$11,216.00 - $17,578.00

Business Financing Available

Mounting
Size

WAIN ROY RIPPER BUCKETS

Ripper Buckets are used in wide variety of severe applications where material is being both ripped and removed. Rip and dig with one attachment to increase performance and efficiency. As the current pass is dug and removed, the next pass is ripped and prepared. Standard applications for Ripper Buckets would include: frozen ground, sandstone, limestone, caliche, shale, coral, and other severe materials.

Bucket sizes shown are nominal. The Ripper Bucket will cut approximately 2 inches more than the nominal advertised width.

EXCAVATORS 20,000 - 30,000 LBS.

RIPPER BUCKET

OEM PIN ON

 WIDTH CAPACITY (CU. YD.)  LBS CUTTING EDGE TEETH
RB12PO-18 18" 0.30 890 3
RB12PO-24 24" 0.46 1010 3
RB12PO-30 30" 0.59 1310 4
RB12PO-36 36" 0.72 1640 5

RIPPER BUCKET

WAIN ROY XLS, ORIGINAL

GANNON / CP / TAG

 WIDTH CAPACITY (CU. YD.) LBS CUTTING EDGE TEETH
RB12QC-18 18" 0.30 820 3
RB12QC-24 24"
 0.46 950 3
RB12QC-30 30" 0.58 1245 5
RB12QC-36 36"
 0.72 1580 5
MAKE MODELS: 12 TON 20,000 - 30,000 LBS
CASE
  • 9010B, CX130B, CX130D, CX135 MSR, CX145
CAT
  • 311 D LRR, 311C, 311F LRR (2017), 312C L, 312D, 312D L, 313F L GC (2017), 314D, 315F, A-link, M313C
DOOSAN
  • 1202, DX140, S140LCV
HITACHI
  • ZX120, ZX120-3, ZX130-6, ZX135, ZX135US-3
HYUNDIA
  • HW140, HX130LCR, HX140L, HX145LCR, R110D-7, R125LCR09A, R140LC-7, R140LC-9, R140LC-9A, R140LCD-7, R140W-9, R140W-9A, R145LCR-9, R145LCR-9A
JCB
  • HYDRADIG 110W, JS130LC, JS131, JS145, JZ141
JOHN DEERE
  • 110, 120C, 120D, 130G, 135C RTS, 135D, 135G, 490D, 490E
KOBELCO
  • 115SRDZ, 135SRLCOSB, 140SR
KOMATSU
  • PC100-6, PC120-6, PC128UU-2, PC130-8, PC138USLC-11, PC138USLC-2, PC158USLC-2, PC20LC-6
LIEBHERR
  • A309, A311, A312
LINK BELT
  • 130 X2, 130 X3, 130 X4, 130LX, 135MSR, 145 X3 Spin Ace (Tier 4a), 145 X4 Spin Ace, 210LX-LF, 240LX-LF
MECALAC
  • 11MWR
NEW HOLLAND
  • E135B, EH130LC
SANY
  • SY135C-Tier 2
TEREX
  • TC125 (hr42), TC140LC-1, TW110, TW130
VERMEER
  • CX224, CX229, CX234
VOLVO
  • EC140B-LC, EC140C, EC140E, ECR145C, ECR145E
WACKER NEUSON
  • GE1202, ME12002
