WTB1-36-050
WERK-BRAU Hydraulic Actuator Tilt Bucket for 7,500 - 11,000 lbs. Backhoes (U2)
$10,140.00 - $10,807.00
3/24
WERK-BRAU HYDRAULIC ACTUATOR TILT BUCKETS
Recommended Applications
With the Werk-Brau Actuator Tilt Ditching bucket, you can tilt any bucket up to 90 degrees each way (180 degrees total) vs. 45 degrees each way in a cylinder design. This bucket design eliminates minimum width constraints like a typical cylinder version.
Key Features
Instead of tilt cylinders, Werk-Brau offers their tilting grade bucket with a rotary actuator to achieve more tilting range of motion, tilting force, and also less downtime and maintenance. Productivity can increase by up to 50% by simply tilting your attachments. The tilting function is powered by a fully enclosed rotary actuator with improved tilt holding force. With no exposed cylinders, this bucket reduces downtime.
| PART # | WIDTH | CAPACITY | WEIGHT |
| WTB1-36-050 | 36" | 5.50 | 609 |
| WTB1-42-050 | 42" | 6.50 | 675 |
| WTB1-48-050 | 48" | 7.50 | 713 |
| MAKE | MODEL |
| Catepillar | 416F, 420F, 426F, 430F, 436 |
| John Deere | 310E, 310G, 310J, 310K, 310L, 310P |
| JCB | 214, 215, 3CX, 4CX |
| komatsu | WB140-2, WB140-PS-2, WB150-2, WB150PS-2 |
