QB821L
WERK-BRAU Multi-Purpose Quad Bucket for Wheel loaders / backhoes 10,000 - 14,000 lbs. (BH)
$10,269.00 - $12,082.00
9/25
MULTI-PURPOSE QUAD BUCKET (4-IN-1)
Recommended Applications
Specifically designed to add versatility to a standard loader bucket. Can be used for light grading, backfilling, material handling as well as loading. Not designed to be used in heavy rock applications.
Quality Construction
High strength, wear resistant steel is used in cutting edges. High quality cylinders are utilized in all models. All pivot points are greaseable and lined with hardened bushings. Each bucket is engineered with tapered side plates to reduce wear on the buckets sides, and to allow for easier dumping.
Tooth Equipment Options
Cutting edge can be drilled to accept bolt-on teeth or a replaceable bolt-on edge.
Standard Sizes
Specific widths and capacities made to meet customer requirements.
Additional Features
All models fitted with attaching ears that meet all pertinent OEM specifications. Dozer edge is equipped with replaceable bolt on edge.
- Designed for multipurpose application jobs
- Lifting Loops
- 90° clam rotation
- Dual replaceable edges - Dozer and Clam front edges
- includes bolt on cutting edge
- does not include hose kit
| PART # | WIDTH | CAPACITY | WEIGHT |
| QB821L | 82" | 1.00 cubic yd | 1,600 |
| QB921L | 92" | 1.25 cubic yd | 1,800 |
| QB961L | 96" | 1.38 cubic yd | 1,950 |
| CLASS: BH (10,000-14,000 LBS) | MODEL |
| CASE | 221, 480, 580, 590 680 |
| CAT | 416, 420, 430, 328 |
| DEVELON | |
| HITACHI | |
| HYUNDAI | |
| JCB | 214, 215, 140, 1500 |
| JOHN DEERE | 310, 410, 510, 610 |
| KOMATSU | WB140, WB150 |
| KUBOTA | B26, L47, M62 |
| LIEBHERR | |
| LINK-BELT | |
| NEW HOLLAND | LB90B, LB95B, LB110B, LB115B |
| SANY | |
| TAKEUCHI | |
| VOLVO | BL70, BL71, BL60 |
| WACKER NEUSON | |
| YANMAR |
