EZG-EX20-PRO-3
WERK-BRAU Progressive Link hydraulic thumb for excavators 42,000 - 50,000 lbs. (20MT)
$14,347.00 - $14,680.00
11/24
PROGRESSIVE LINK HYDRAULIC THUMBS
Recommended Applications
The Werk-Brau Progressive Linkage (Pro-Link) Thumb features a full 180 degrees of rotation making it ideal for handling and manipulating a wide variety of material, debris, rocks, logs, and irregular shaped objects. Each tine has a minimum 3 points of grip to keep materials secure.
Quality Construction
T-1 steel is used in all critical and high wear components. The Pro-Link features hardened pins and bushing used at all pivot points.
Sizes Available
Various models available to match machines capacities.
Features
- 180 degree standard rotation
- linkage is self contained
- does not include jumper hose kit
- info form must be completed when thumb is working with any non Werk-Brau attachment
| PART # | NUMBER OF TINES | WEIGHT |
| EZG-EX20-PRO-3 | 3 | 1,500 |
| EZG-EX20-PRO-4 | 4 | 1,540 |
| EZG-EX20-PRO-5 | 5 | 1,640 |
| MAKE / WEIGHT CLASS | 20MT (42,000 - 50,000 LBS.) |
| CASE | CX210, CX220E, CX235, CX245 |
| CAT | 320, 321, M322F, 323 (B-Linkage) |
| DOOSAN | DX210W-5, DX225LC-5, DX225LC-5SLR, DX235LCR-5 |
| HITACHI | ZX180, ZX200, ZX210, ZX245 |
| HYUNDAI | HX220, HX235 |
| JOHN DEERE | 210G, 245G, 180P, 210P, 190GW, 230GW |
| KOBELCO | SK210, SK230SR, SK260, SK270SR |
| KOMATSU | PC210-11, PC228, PC238 |
| LIEBHERR | R 920 L, 922 L |
| LINK BELT | 210X4, 234X4, 245X4 |
| SANY | SY215 |
| TAKEUCHI | |
| VOLVO | EC200, EW210, EC210, EC220, ECR235 |
